USB Console Extender with RS232 and audio

$482.30

Qty:

The CE750 USB Console Extender allows access to a computer or USB KVM from a remote console from up to 490 ft. away.

Write a Review

Manufacturer: ATEN Technology Inc.

SKU: CE750

GTIN: 00672792100604

The CE750 USB Console Extender allows access to a computer or USB KVM from a remote console from up to 490 ft. away. This extender is unique in that it not only supports Audio, but both units incorporate a RS232 port for serial devices such as barcode scanners, and touch screens. The CE750 is an ideal solution for any installation requiring computers to be kept in controlled spaces, whether it be for security or environmental concerns, and with the added RS232 functionality, the unit is perfect for use in kiosks and other applications requiring extended serial connectivity

Local and Remote Units connect with Cat5e cable
Video Resolutions up to 1600 x 1200 @ 60 Hz (490 ft) or 1280 x 1024 @60 Hz (650 ft)
Dual console operation and control your system from either the local or remote consoles
Built-in ASIC for greater reliability and compatibility
USB Keyboard and USB Mouse Ports
RS-232 serial ports - allows connections to a serial terminal for configurations (Local Unit), or serial devices such as touch screens and barcode scanners (Remote Unit)
Supports powered computer stereo speakers and microphones
USB over current protection
Pushbutton mode selection (Local Unit only) and selects Local (Remote lock out) or Auto operating modes.
Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV) and 2KV surge protection
Adjustable gain control and manually adjusts signal strength fordistance compensation
Supports VGA, SVGA, SXGA (1280 x 1024) and UXGA (1600 x 1200) and multi-sync monitors; local monitor supports DDC; DDC2; DDC2B
Hot pluggable
Rack mountable
Easy to install and no software required and connecting cables to the devices is all it takes

Products specifications

Manufacturer	ATEN Technology Inc.
SKU	CE750
GTIN	00672792100604
Weight (Lbs)	4.80
